🟦 Product Overview

JIS Angle Steel is produced according to JIS G3192, the Japanese standard for hot‑rolled steel sections. It includes:

• Equal Angle
• Unequal Angle

JIS angles are widely used in Japan, Southeast Asia, and global EPC projects requiring Japanese‑standard structural steel. They are known for:

• Excellent dimensional accuracy
• Reliable mechanical performance
• High weldability
• Consistent quality for structural and mechanical applications

Common material grades include SS400, SM490, and SM520, covering both general structural steel and high‑strength welded structural steel.

🟦 Applicable Standards

• JIS G3192 – Dimensions, shape, mass, and permissible variations of hot‑rolled steel sections
• JIS G3101 – Rolled steels for general structure (SS400)
• JIS G3106 – Rolled steels for welded structures (SM490 / SM520)

🟦 Available Grades

• SS400
• SM490A / SM490B / SM490C
• SM520

These grades provide reliable performance for general and high‑strength structural applications.

🟦 Section Types

Equal Angle (JIS Standard)

• Equal leg lengths
• Suitable for structural and architectural applications
• Designation example: L 100 × 100 × 10

Unequal Angle (JIS Standard)

• Different leg lengths
• Ideal for bracing, framing, and reinforcement
• Designation example: L 150 × 90 × 12

🟦 Dimensions Range

Type	Leg Size (mm)	Thickness (mm)	Length
Equal Angle	20×20 – 200×200	3–20	6 m / 9 m / 12 m / custom
Unequal Angle	30×20 – 250×90	3–20	6 m / 9 m / 12 m / custom

Tolerance: As per JIS G3192

🟦 Mechanical Properties

SS400

Property	Value
Yield Strength	245–275 MPa
Tensile Strength	400–510 MPa
Elongation	≥ 20%

SM490

Property	Value
Yield Strength	≥ 325 MPa
Tensile Strength	490–610 MPa
Elongation	≥ 18%

🟦 Chemical Composition (Typical)

SM490

Element	Max (%)
C	0.20
Mn	1.60
P	0.035
S	0.035
Si	0.55

🟦 Applications

• Building structures
• Industrial steel frameworks
• Machinery and equipment support
• Civil engineering projects
• Structural reinforcement
• Welded assemblies

🟦 Why Use JIS Angle Steel

• Standardized Japanese dimensions
• Excellent weldability and fabrication properties
• Reliable mechanical performance
• Suitable for Asian and global EPC projects
• Wide range of sizes and grades

🟦 Why Choose Jaron Steel

• Full range of JIS G3192 equal & unequal angles
• SS400 / SM490 / SM520 grades available
• CNC cutting, drilling, and fabrication services
• SGS / BV third‑party inspection available
• Export‑grade seaworthy packaging
• Fast delivery from stock and mill production
