Description
🟦 Product Overview
S355 Honed Tube is a precision‑finished seamless steel tube designed for hydraulic and pneumatic cylinder applications. Manufactured from S355 structural steel, it offers excellent mechanical strength, dimensional accuracy, and surface finish.
The inner surface is honed or skived & roller‑burnished to achieve a mirror‑like finish, ensuring smooth piston movement and extended seal life.
🟦 Key Features
- High strength and toughness (S355 grade)
- Excellent internal surface finish (Ra ≤ 0.4 μm)
- Precise dimensional tolerance (H8 / H9)
- Suitable for hydraulic and pneumatic cylinders
- Long service life and low friction performance
🟦 Standards
- EN 10297‑1 (Seamless Circular Tubes for Mechanical and General Engineering Purposes)
- EN 10305‑1 (Precision Steel Tubes – Seamless Cold Drawn)
- DIN 2391 / ISO 4394
- ASTM A519 (Equivalent Standard)
🟦 Chemical Composition（S355）
| Element | Content (%) |
|---|---|
| C | ≤ 0.22 |
| Mn | ≤ 1.60 |
| Si | ≤ 0.55 |
| P | ≤ 0.035 |
| S | ≤ 0.035 |
| Fe | Balance |
🟦 Mechanical Properties（Typical）
| Property | Requirement |
|---|---|
| Yield Strength | ≥ 355 MPa |
| Tensile Strength | 470–630 MPa |
| Elongation | ≥ 22% |
| Hardness | ≤ 180 HB |
🟦 Dimensional Range
| Outer Diameter | Wall Thickness | Length |
|---|---|---|
| 40–500 mm | 5–50 mm | Up to 12 m |
Tolerance: ISO H8 / H9 Surface Roughness: Ra ≤ 0.4 μm Straightness: ≤ 0.3 mm/m
🟦 Manufacturing Process
- Hot‑rolled seamless tube (S355)
- Cold drawing for precision dimension
- Honing or skiving & roller burnishing
- Ultrasonic testing and dimensional inspection
- Anti‑rust oil coating and protective packaging
🟦 Applications
- Hydraulic cylinders
- Pneumatic cylinders
- Mechanical actuators
- Lifting equipment
- Construction machinery
- Industrial automation systems
🟦 Why Choose Jaron Steel
- Full range of S355 honed tubes in stock
- Precision machining and surface finishing
- MTC EN 10204 3.1 certification
- SGS / BV / TUV inspection available
- Export‑grade packaging and fast delivery
🟦 Short Description
- Grade: S355
- Type: Honed Hydraulic Cylinder Tube
- Standard: EN 10297‑1 / EN 10305‑1
- Size Range: 40–500 mm OD
- Applications: Hydraulic & pneumatic cylinders
- Key Feature: High precision, smooth inner surface, long service life
